Parameter Option Default Function
8-30 Protocol
[0] FC
[2] Modbus RTU
0 Select the protocol for the integrated RS-485
port.
8-32 Baud Rate
[0] 2400 Baud
[1] 4800 Baud
[2] 9600 Baud
[3] 19200 Baud
[4] 38400 Baud
[5] 57600 Baud
[6] 76800 Baud
[7] 115200 Baud
[2] 9600 Baud Select the baud rate for the RS-485 port.
20-00 Feedback 1 Source
[0] No function
[1] Analog Input 53
[2] Analog Input 54
[3] Pulse input 29
[100] Bus Feedback 1
[101] Bus Feedback 2
[0] No function Select which input will be used as the source
of the feedback signal.
20-81 PI Normal/ Inverse Control
[0] Normal
[1] Inverse
[0] Normal Select how the feedback should be calculated
Table 1.15 Closed Loop Applications Set-up
Changes made
Changes Made lists all parameters changed from default
settings.
•
The list shows only parameters which have been
changed in the current edit-setup.
•
Parameters which have been reset to default
values are not listed.
•
The message Empty indicates that no parameters
have been changed.
To change parameter settings
1. Press [Menu] key to enter the Quick Menu until
indicator in display is placed above Quick Menu.
2.
Press [
▲
] [
▼
] to select wizard, closed loop set-up,
compressor set-up or changes made, then press
[OK].
3.
Press [
▲
] [
▼
] to browse through the parameters
in the Quick Menu.
4. Press [OK] to select a parameter.
5.
Press [
▲
] [
▼
] to change the value of a parameter
setting.
6. Press [OK] to accept the change.
7. Press either [Back] twice to enter Status, or press
[Menu] once to enter Main Menu.
The Main Menu accesses all parameters
1. Press [Menu] until indicator in display is placed
above Main Menu.
2.
Press [
▲
] [
▼
] to browse through the parameter
groups.
3. Press [Ok] to select a parameter group.
4.
Press [
▲
] [
▼
] to browse through the parameters
in the specific group.
5. Press [Ok] to select the parameter.
6.
Press [
▲
] [
▼
] to set/change the parameter value.
Quick Guide Quick Guide
20 Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102
