Danfoss VLT CDS 803 Programming Guide

Parameter Option Default Function
Parameter 0-06 GridType [0] 200–240 V/50 Hz/IT-grid
[1] 200–240 V/50 Hz/Delta
[2] 200–240 V/50 Hz
[10] 380–440 V/50 Hz/IT-grid
[11] 380–440 V/50 Hz/Delta
[12] 380–440 V/50 Hz
[20] 440–480 V/50 Hz/IT-grid
[21] 440–480 V/50 Hz/Delta
[22] 440–480 V/50 Hz
[30] 525–600 V/50 Hz/IT-grid
[31] 525–600 V/50 Hz/Delta
[32] 525–600 V/50 Hz
[100] 200–240 V/60 Hz/IT-grid
[101] 200–240 V/60 Hz/Delta
[102] 200–240 V/60 Hz
[110] 380–440 V/60 Hz/IT-grid
[111] 380–440 V/60 Hz/Delta
[112] 380–440 V/60 Hz
[120] 440–480 V/60 Hz/IT-grid
[121] 440–480 V/60 Hz/Delta
[122] 440–480 V/60 Hz
[130] 525–600 V/60 Hz/IT-grid
[131] 525–600 V/60 Hz/Delta
[132] 525–600 V/60 Hz
Size related Select operating mode for restart after
reconnection of the frequency converter to
mains voltage after power-down.
Parameter 0-60 Main Menu Password 0–999 0 Dene the password for access to the LCP.
Parameter 1-13 Compressor Selection [24] VZH028-R410A
[25] VZH035-R410A
[26] VZH044-R410A
[27] VLZ028
[28] VLZ035
[29] VLZ044
Size related Select which compressor to use.
Parameter 3-03 Maximum Reference 0–200 Hz 200 Hz The maximum reference is the highest
obtainable by summing all references.
Parameter 3-15 Reference 1 Source [0] No function
[1] Analog in 53
[2] Analog in 54
[7] Pulse input 29
[11] Local bus reference
[1] Analog in 53 Select the input to be used for the reference
signal.
Parameter 3-41 Ramp 1 Ramp Up
Time
0.05–3600.0 s 90.00 s Ramp-up time from 0 to parameter 1-25 Motor
Nominal Speed.
Parameter 3-42 Ramp 1 Ramp Down
Time
0.05–3600.0 s 30.00 s Ramp-down time from nominal motor speed
to 0.
How to Program
VLT
®
Compressor Drive CDS 803
10 Danfoss A/S © 06/2019 All rights reserved. MG18P202
