Selected

preset

reference:

Preset

reference

bit 2

Preset

reference

bit 1

Preset

reference

bit 0

Preset

reference 0

0 0 0

Preset

reference 1

0 0 1

Preset

reference 2

0 1 0

Preset

reference 3

0 1 1

Preset

reference 4

1 0 0

Preset

reference 5

1 0 1

Preset

reference 6

1 1 0

Preset

reference 7

1 1 1

Table 3.3 Selected Preset Reference

5-10 Terminal 18 Digital Input

Parameter for conguring the input function on input terminal

18. Refer to Table 3.2 for setting options.

Option: Function:

[0] No operation

[1] Reset

[2] Coast inverse

[3] Coast and

reset inverse

[4] Quick stop

inverse

[5] DC-brake

inverse

[6] Stop inverse

[7] External

Interlock

[8] * Start

[9] Latched start

[10] Reversing

[11] Start reversing

[14] Jog

[16] Preset ref bit 0

[17] Preset ref bit 1

[18] Preset ref bit 2

[19] Freeze

reference

[20] Freeze output

[21] Speed up

[22] Speed down

[23] Set-up select

bit 0

[34] Ramp bit 0

5-10 Terminal 18 Digital Input

Parameter for conguring the input function on input terminal

18. Refer to Table 3.2 for setting options.

Option: Function:

[52] Run

permissive

[53] Hand start

[54] Auto start

[60] Counter A (up)

[61] Counter A

(down)

[62] Reset Counter

[63] Counter B (up)

[64] Counter B

(down)

[65] Reset Counter

5-11 Terminal 19 Digital Input

Parameter for conguring the input function on input terminal

19.

Option: Function:

[0] * No operation

[1] Reset

[2] Coast inverse

[3] Coast and

reset inverse

[4] Quick stop

inverse

[5] DC-brake

inverse

[6] Stop inverse

[7] External

Interlock

[8] Start

[9] Latched start

[10] Reversing

[11] Start reversing

[14] Jog

[16] Preset ref bit 0

[17] Preset ref bit 1

[18] Preset ref bit 2

[19] Freeze

reference

[20] Freeze output

[21] Speed up

[22] Speed down

[23] Set-up select

bit 0

[34] Ramp bit 0

[52] Run

permissive

[53] Hand start

[54] Auto start

Parameters

VLT

Compressor Drive CDS 803
