Danfoss VLT CDS 803 Programming Guide

5-11 Terminal 19 Digital Input
Parameter for conguring the input function on input terminal
19.
Option: Function:
[60] Counter A (up)
[61] Counter A
(down)
[62] Reset Counter
A
[63] Counter B (up)
[64] Counter B
(down)
[65] Reset Counter
B
5-12 Terminal 27 Digital Input
Parameter for conguring the input function on input terminal
27.
Option: Function:
[0] No operation
[1] Reset
[2] Coast inverse
[3] Coast and
reset inverse
[4] Quick stop
inverse
[5] DC-brake
inverse
[6] Stop inverse
[7] External
Interlock
[8] Start
[9] Latched start
[10] Reversing
[11] Start reversing
[14] Jog
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
[19] Freeze
reference
[20] Freeze output
[21] Speed up
[22] Speed down
[23] Set-up select
bit 0
[34] Ramp bit 0
[52] Run
permissive
[53] Hand start
[54] Auto start
[60] Counter A (up)
[61] Counter A
(down)
5-12 Terminal 27 Digital Input
Parameter for conguring the input function on input terminal
27.
Option: Function:
[62] Reset Counter
A
[63] Counter B (up)
[64] Counter B
(down)
[65] Reset Counter
B
5-13 Terminal 29 Digital Input
Parameter for conguring the input function on input terminal
29.
Option: Function:
[0] No operation
[1] * Reset
[2] Coast inverse
[3] Coast and
reset inverse
[4] Quick stop
inverse
[5] DC-brake
inverse
[6] Stop inverse
[7] External
Interlock
[8] Start
[9] Latched start
[10] Reversing
[11] Start reversing
[14] Jog
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
[19] Freeze
reference
[20] Freeze output
[21] Speed up
[22] Speed down
[23] Set-up select
bit 0
[32] Pulse input
[34] Ramp bit 0
[52] Run
permissive
[53] Hand start
[54] Auto start
[60] Counter A (up)
[61] Counter A
(down)
[62] Reset Counter
A
[63] Counter B (up)
Parameters Programming Guide
MG18P202 Danfoss A/S © 06/2019 All rights reserved. 31
3 3
