3.8.3 8-4* FC MC Protocol Set
This parameter group is for PCD write and read congu-
rations.
8-42 PCD Write Conguration
Dierent parameters can be assigned to PCD 3 to 10 of the PPOs
(the number of PCDs depends on the PPO type). The values in
PCD 3 to10 will be written to the selected parameters as data
values.
Option: Function:
[0] None
[1] [302]
Minimum
Reference
[2] [303]
Maximum
Reference
[3] [341] Ramp 1
Ramp up time
[4] [342] Ramp 1
Ramp down
time
[5] [351] Ramp 2
Ramp up time
[6] [352] Ramp 2
Ramp down
time
[7] [380] Jog
Ramp Time
[8] [381] Quick
Stop Time
[9] [412] Motor
Speed Low
Limit [Hz]
[10] [414] Motor
Speed High
Limit [Hz]
[11] [590] Digital &
Relay Bus
Control
[12] [676] Terminal
45 Output Bus
Control
[13] [696] Terminal
42 Output Bus
Control
[14] [894] Bus
Feedback 1
[15] FC Port CTW
[16] FC Port REF
8-43 PCD Read Conguration
Select the parameters to be assigned to PCD's of the telegrams.
The number of available PCDs depends on the telegram type.
PCDs contain the actual data values of the selected parameters.
Option: Function:
[0] None
[1] [1500]
Operation
Hours
[2] [1501]
Running Hours
[3] [1502] kWh
Counter
[4] [1600] Control
Word
[5] [1601]
Reference
[Unit]
[6] [1602]
Reference %
[7] [1603] Status
Word
[8] [1605] Main
Actual Value
[%]
[9] [1609] Custom
Readout
[10] [1610] Power
[kW]
[11] [1611] Power
[hp]
[12] [1612] Motor
Voltage
[13] [1613]
Frequency
[14] [1614] Motor
Current
[15] [1615]
Frequency [%]
[16] [1616] Torque
[Nm]
[17] [1618] Motor
Thermal
[18] [1630] DC Link
Voltage
[19] [1634]
Heatsink
Temp.
[20] [1635] Inverter
Thermal
[21] [1638] SL
Controller
State
[22] [1650] External
Reference
Parameters
VLT
®
Compressor Drive CDS 803
42 Danfoss A/S © 06/2019 All rights reserved. MG18P202
