8-43 PCD Read Conguration
Select the parameters to be assigned to PCD's of the telegrams.
The number of available PCDs depends on the telegram type.
PCDs contain the actual data values of the selected parameters.
Option: Function:
[23] [1652]
Feedback
[Unit]
[24] [1660] Digital
Input
18,19,27,33
[25] [1661]
Terminal 53
Switch Setting
[26] [1662] Analog
input 53
[27] [1663]
Terminal 54
Switch Setting
[28] [1664] Analog
input 54
[29] [1665] Analog
output 42
[mA]
[30] [1671] Relay
output
[31] [1672] Counter
A
[32] [1673] Counter
B
[33] [1690] Alarm
Word
[34] [1692]
Warning Word
[35] [1694] Ext.
Status Word
[37] [2860] RPS
Readout
[39] [1691] Alarm
Word 2
[40] [1693]
Warning Word
2
[43] [1617] Speed
[RPM]
[44] [1666] Digital
Output
3.8.4 8-5* Digital/Bus
Parameters for conguring the control word digital/bus
merging.
8-50 Coasting Select
Select control of the coasting function via the terminals (digital
input) and/or via the bus. This parameter is only active when
parameter 8-01 Control Site is set to [0] Digital and control word.
Option: Function:
[0] Digital input Activates coast via a digital input.
[1] Bus Activates coast via the serial
communication port.
[2] Logic AND Activates coast via the eldbus/
serial communication port, and via
1 of the digital inputs.
[3] * Logic OR Activates coast via the serial
communication port or via 1 of the
digital inputs.
8-51 Quick Stop Select
Select control of the quick stop function via the terminals (digital
input) and/or via the bus. This parameter is only active when
parameter 8-01 Control Site is set to [0] Digital and control word.
Option: Function:
[0] Digital input Activates quick stop via a digital
input.
[1] Bus Activates quick stop via the serial
communication port.
[2] Logic AND Activates quick stop via the serial
communication port and via 1 of
the digital inputs.
[3] * Logic OR Activates quick stop via the serial
communication port or via 1 of the
digital inputs.
8-52 DC Brake Select
Select control of the DC brake via the terminals (digital
input).This parameter is only active when parameter 8-01 Control
Site is set to [0] Digital and control word.
Option: Function:
[0] Digital input Activates DC brake via a digital
input.
[1] Bus Activates DC brake via the serial
communication port.
[2] Logic AND Activates DC brake via the serial
communication port, AND also via
one of the digital inputs.
[3] * Logic OR Activates DC brake via the serial
communication port OR via one of
the digital inputs.
Parameters Programming Guide
MG18P202 Danfoss A/S © 06/2019 All rights reserved. 43
