Danfoss VLT CDS 803 Programming Guide

13-02 Stop Event
Select the condition (TRUE or FALSE) which deactivates the smart
logic controller.
Option: Function:
[7] Out of current
range
See parameter 13-01 Start Event for
further description.
[8] Below I low See parameter 13-01 Start Event for
further description.
[9] Above I high See parameter 13-01 Start Event for
further description.
[16] Thermal
warning
See parameter 13-01 Start Event for
further description.
[17] Mains out of
range
See parameter 13-01 Start Event for
further description.
[18] Reversing See parameter 13-01 Start Event for
further description.
[19] Warning See parameter 13-01 Start Event for
further description.
[20] Alarm (trip) See parameter 13-01 Start Event for
further description.
[21] Alarm (trip
lock)
See parameter 13-01 Start Event for
further description.
[22] Comparator 0 Use the result of comparator 0 in
the logic rule.
[23] Comparator 1 Use the result of comparator 1 in
the logic rule.
[24] Comparator 2 Use the result of comparator 2 in
the logic rule.
[25] Comparator 3 Use the result of comparator 3 in
the logic rule.
[26] Logic rule 0 Use the result of logic rule 0 in the
logic rule.
[27] Logic rule 1 Use the result of logic rule 1 in the
logic rule.
[28] Logic rule 2 Use the result of logic rule 2 in the
logic rule.
[29] Logic rule 3 Use the result of logic rule 3 in the
logic rule.
[30] SL Time-out 0 Use the result of timer 0 in the
logic rule.
[31] SL Time-out 1 Use the result of timer 1 in the
logic rule.
[32] SL Time-out 2 Use the result of timer 2 in the
logic rule.
[33] Digital input
DI18
Use the value of DI18 in the logic
rule (High=TRUE).
[34] Digital input
DI19
Use the value of DI19 in the logic
rule (High=TRUE).
13-02 Stop Event
Select the condition (TRUE or FALSE) which deactivates the smart
logic controller.
Option: Function:
[35] Digital input
DI27
Use the value of DI27 in the logic
rule (High=TRUE).
[36] Digital input
DI29
Use the value of DI29 in the logic
rule (High=TRUE).
[39] Start
command
This event is TRUE if the frequency
converter is started by any means
(either via digital input, eldbus or
other).
[40] * Drive stopped This event is TRUE if the frequency
converter is stopped or coasted by
any means (either via digital input,
eldbus or other).
[42] Auto Reset
Trip
This event is TRUE if the frequency
converter is tripped (but not trip
lock) and an automatic reset is
issued.
[50] Comparator 4 Use the result of comparator 4 in
the logic rule.
[51] Comparator 5 Use the result of comparator 5 in
the logic rule.
[60] Logic rule 4 Use the result of logic rule 4 in the
logic rule.
[61] Logic rule 5 Use the result of logic rule 5 in the
logic rule.
[70] SL Time-out 3 Use the result of timer 3 in the
logic rule.
[71] SL Time-out 4 Use the result of timer 4 in the
logic rule.
[72] SL Time-out 5 Use the result of timer 5 in the
logic rule.
[73] SL Time-out 6 Use the result of timer 6 in the
logic rule.
[74] SL Time-out 7 Use the result of timer 7 in the
logic rule.
13-03 Reset SLC
Option: Function:
[0] * Do not reset
SLC
Retains programmed settings in
parameter group 13-** Smart Logic.
[1] Reset SLC Resets all parameters in parameter
group 13-** Smart Logic to default
settings.
Parameters Programming Guide
MG18P202 Danfoss A/S © 06/2019 All rights reserved. 47
3 3
