Danfoss VLT CDS 803 Programming Guide

Bit Bit = 0 Bit = 1
00 Preset reference option lsb –
01
Preset reference option 2
nd
bit of
preset references
–
02 DC brake Ramp
03 Coasting Enable
04 Quick stop Ramp
05 Freeze output Ramp
06 Ramp stop Start
07 No function Reset
08 No function Jog
09 Ramp 1 Ramp 2
10 Data not valid Valid
11 Relay_A not active Relay_A activated
12 Relay_B not active Relay_B activated
13 Choice of set-up lsb –
14 No function No function
15 No function Reversing
Table 3.5 Control Word
16-01 Reference [Unit]
Range: Function:
0 Referen-
ceFeedback
Unit*
[-4999 - 4999
Reference-
FeedbackUnit]
View the present reference value
applied on impulse or analog basis
in the unit resulting from the
conguration selected in
parameter 1-00 Conguration Mode.
16-02 Reference [%]
Range: Function:
0 %* [-200 -
200 %]
View the total reference. The total
reference is the sum of digital,
analog, preset, bus, and freeze
references.
16-03 Status Word
Range: Function:
0* [0 - 65535 ] View the status word sent from the
frequency converter via the serial
communication port in hex code.
Bit Bit=0 Bit=1
00 Control not ready Ready
01 VLT not ready Ready
02 Coasting Enable
03 No fault Trip
04 No warning Warning
05 Reserved –
06 No trip lock Trip lock
07 No warning Warning
08
Speed≠ref.
Speed=ref.
09 Local control Bus control
10 Out of range Frequency OK
11 Not running Running
12 No function No function
13 Voltage OK Above limit
14 Current OK Above limit
15 Temperature OK Above limit
Table 3.6 Status Word
16-05 Main Actual Value [%]
Range: Function:
0 %* [-200 -
200 %]
View the 2 byte word sent with the
status word to the bus master
reporting the main actual value.
16-09 Custom Readout
Range: Function:
0 Custom-
ReadoutUni
t*
[0 - 9999
CustomRea-
doutUnit]
View the user-dened readouts as
dened in parameter 0-30 Custom
Readout Unit,
parameter 0-31 Custom Readout Min
Value, and parameter 0-32 Custom
Readout Max Value.
3.12.2 16-1* Motor Status
16-10 Power [kW]
Range: Function:
0 kW* [0 - 1000
kW]
Shows the actual compressor power
in kW. The value shown is
calculated based on the actual
compressor voltage and compressor
current.
16-11 Power [hp]
Range: Function:
0 hp* [0 - 1000 hp] View the actual compressor power
in hp. The value shown is
calculated based on the actual
compressor voltage and compressor
current.
Parameters Programming Guide
MG18P202 Danfoss A/S © 06/2019 All rights reserved. 59
3 3
