ALARM 82, CSIV parameter error
CSIV failed to init a parameter.
ALARM 85, Dang fail PB:
Profibus/Profisafe Error.
WARNING/ALARM 104, Mixing fan fault
The fan monitor checks that the fan is spinning at drive
power-up or whenever the mixing fan is turned on. If the
fan is not operating, then the fault is annunciated. The
mixing-fan fault can be configured as a warning or an
alarm trip by parameter 14-53 (Fan Monitor).
Troubleshooting Cycle power to the frequency converter
to determine if the warning/alarm returns.
ALARM 243, Brake IGBT
This alarm is only for F Frame frequency converters. It is
equivalent to Alarm 27. The report value in the alarm log
indicates which power module generated the alarm:
1 = left most inverter module.
2 = middle inverter module in F12 or F3 frame
sizes .
2 = right inverter module in F10 or F11 frame
sizes.
2 = second drive from the left inverter module in
F14 frame size.
3 = right inverter module in F12 or F13 frame
sizes.
3 = third from the left intverter module in F14
frame size.
4 = far right inverter module in F14 frame size.
5 = rectifier module.
6 = right rectifier module in F14 frame size.
ALARM 244, Heatsink temperature
This alarm is only for F Frame frequency converters. It is
equivalent to Alarm 29. The report value in the alarm log
indicates which power module generated the alarm.
1 = left most inverter module.
2 = middle inverter module in F12 or F3 frame
sizes .
2 = right inverter module in F10 or F11 frame
sizes.
2 = second drive from the left inverter module in
F14 frame size.
3 = right inverter module in F12 or F13 frame
sizes.
3 = third from the left intverter module in F14
frame size.
4 = far right inverter module in F14 frame size.
5 = rectifier module.
6 = right rectifier module in F14 frame size.
ALARM 245, Heatsink sensor
This alarm is only for F Frame frequency converters. It is
equivalent to Alarm 39. The report value in the alarm log
indicates which power module generated the alarm
1 = left most inverter module.
2 = middle inverter module in F12 or F3 frame
sizes .
2 = right inverter module in F10 or F11 frame
sizes.
2 = second drive from the left inverter module in
F14 frame size.
3 = right inverter module in F12 or F13 frame
sizes.
3 = third from the left intverter module in F14
frame size.
4 = far right inverter module in F14 frame size.
5 = rectifier module.
6 = right rectifier module in F14 frame size.
ALARM 246, Power card supply
This alarm is only for F Frame frequency converter. It is
equivalent to Alarm 46. The report value in the alarm log
indicates which power module generated the alarm
1 = left most inverter module.
2 = middle inverter module in F12 or F3 frame
sizes .
2 = right inverter module in F10 or F11 frame
sizes.
2 = second drive from the left inverter module in
F14 frame size.
3 = right inverter module in F12 or F13 frame
sizes.
3 = third from the left intverter module in F14
frame size.
4 = far right inverter module in F14 frame size.
5 = rectifier module.
6 = right rectifier module in F14 frame size.
ALARM 69, Power card temperaturePower card
temperature
This alarm is only for F Frame frequency converter. It is
equivalent to Alarm 69. The report value in the alarm log
indicates which power module generated the alarm
1 = left most inverter module.
2 = middle inverter module in F12 or F3 frame
sizes .
2 = right inverter module in F10 or F11 frame
sizes.
2 = second drive from the left inverter module in
F14 frame size.
Warnings and Alarms
VLT
®
Automation Drive FC 300 12-Pulse
Operating Instructions High Power
110 MG34Q202 - VLT
®
is a registered Danfoss trademark
6
6
