4.2 Quick Setup
0-01 Language
Option: Function:
Defines the language to be used in the
display. The frequency converter can be
delivered with 4 different language
packages. English and German are
included in all packages. English cannot
be erased or manipulated.
[0] * English Part of Language packages 1 - 4
[1] Deutsch Part of Language packages 1 - 4
[2] Francais Part of Language package 1
[3] Dansk Part of Language package 1
[4] Spanish Part of Language package 1
[5] Italiano Part of Language package 1
Svenska Part of Language package 1
[7] Nederlands Part of Language package 1
[10] Chinese Part of Language package 2
Suomi Part of Language package 1
[22] English US Part of Language package 4
Greek Part of Language package 4
Bras.port Part of Language package 4
Slovenian Part of Language package 3
Korean Part of Language package 2
Japanese Part of Language package 2
Turkish Part of Language package 4
Trad.Chinese Part of Language package 2
Bulgarian Part of Language package 3
Srpski Part of Language package 3
Romanian Part of Language package 3
Magyar Part of Language package 3
Czech Part of Language package 3
Polski Part of Language package 4
Russian Part of Language package 3
Thai Part of Language package 2
Bahasa Indonesia Part of Language package 2
[52] Hrvatski
1-20 Motor Power [kW]
Range: Function:
Application dependent* [Application dependant]
1-22 Motor Voltage
Range: Function:
Size
related*
[ 10. -
1000. V]
Enter the nominal motor voltage
according to the motor nameplate
data. The default value corresponds to
the nominal rated output of the unit.
This parameter cannot be adjusted
while the motor is running.
1-23 Motor Frequency
Range: Function:
Application
dependent*
[20 -
1000
Hz]
Min - Max motor frequency: 20-1000 Hz.
Select the motor frequency value from
the motor nameplate data. If a value
different from 50 Hz or 60 Hz is selected,
it is necessary to adapt the load
independent settings in 1-50 Motor
Magnetisation at Zero Speed to 1-53 Model
Shift Frequency. For 87 Hz operation with
230/400 V motors, set the nameplate
data for 230 V/50 Hz. Adapt 4-13 Motor
Speed High Limit [RPM] and
3-03 Maximum Reference to the 87 Hz
application.
1-24 Motor Current
Range: Function:
Size
related*
[ 0.10 -
10000.00 A]
Enter the nominal motor current
value from the motor nameplate
data. This data is used for
calculating motor torque, motor
thermal protection etc.
NOTE
This parameter cannot be changed while the motor is
running.
1-25 Motor Nominal Speed
Range: Function:
Size related* [100 - 60000
RPM]
Enter the nominal motor speed
value from the motor nameplate
data. This data is used for
calculating automatic motor
compensations.
NOTE
This parameter cannot be changed while the motor is
running.
How to Programme
VLT
®
Automation Drive FC 300 12-Pulse
Operating Instructions High Power
MG34Q202 - VLT
®
is a registered Danfoss trademark 57
4 4
