4.1.2 Initial Commissioning
The easiest way of carrying out the initial commissioning is by using the [Quick Menu] key and follow the quick set-up
procedure using LCP 102 (read table from left to right). The example applies to open loop applications.
Press
Set language
1-20 Motor Power [kW]
Set Motor nameplate power
1-22 Motor Voltage
Set Nameplate voltage
1-23 Motor Frequency
Set Nameplate frequency
1-24 Motor Current
Set Nameplate current
1-25 Motor Nominal Speed
Set Nameplate speed in RPM
5-12 Terminal 27 Digital Input
If terminal default is Coast
inverse it is possible to change
this setting to No function. No
connection to terminal 27 is
then needed for running AMA
1-29 Automatic Motor Adaptation
(AMA)
Set desired AMA function.
Enable complete AMA is
recommended
3-02 Minimum Reference
Set the minimum speed of the
motor shaft
3-03 Maximum Reference
Set the maximum speed of the
motor shaft
3-41 Ramp 1 Ramp up Time
Set the ramping up time with
reference to synchronous
motor speed, n
s
3-42 Ramp 1 Ramp Down Time
Set the ramping down time
with reference to synchronous
motor speed, n
s
3-13 Reference Site
Set the site from where the
reference must work
