Danfoss VLT FC 300 User Manual

Par. No. #
Parameter description Default value 4-set-up FC 302
only
Change during
operation
Conver-
sion index
Type
14-0* Inverter Switching 14-00 Switching Pattern [1] SFAVM All set-ups TRUE - Uint8 14-01 Switching Frequency null All set-ups TRUE - Uint8
14-03 Overmodulation [1] On All set-ups FALSE - Uint8
14-04 PWM Random [0] Off All set-ups TRUE - Uint8 14-1* Mains On/Off 14-10 Line Failure [0] No function All set-ups FALSE - Uint8 14-11 Line Voltage at Line Fault ExpressionLimit All set-ups TRUE 0 Uint16 14-12 Function at Mains Imbalance [0] Trip All set-ups TRUE - Uint8 14-2* Trip Reset 14-20 Reset Mode [0] Manual reset All set-ups TRUE - Uint8 14-21 Automatic Restart Time 10 s All set-ups TRUE 0 Uint16 14-22 Operation Mode [0] Normal operation All set-ups TRUE - Uint8
14-23 Typecode Setting null 2 set-ups FALSE - Uint8
14-25 Trip Delay at Torque Limit 60 s All set-ups TRUE 0 Uint8
14-26 Trip Delay at Inverter Fault ExpressionLimit All set-ups TRUE 0 Uint8
14-28 Production Settings [0] No action All set-ups TRUE - Uint8
14-29
Service Code 0 N/A All set-ups TRUE 0 Int32
14-3* Current Limit Ctrl. 14-30 Current Lim Cont, Proportional Gain 100 % All set-ups FALSE 0 Uint16 14-31 Current Lim Contr, Integration Time 0.020 s All set-ups FALSE -3 Uint16 14-4* Energy Optimizing 14-40 VT Level 66 % All set-ups FALSE 0 Uint8 14-41 AEO Minimum Magnetization 40 % All set-ups TRUE 0 Uint8 14-42 Minimum AEO Frequency 10 Hz All set-ups TRUE 0 Uint8
14-43
Motor Cos-Phi ExpressionLimit All set-ups TRUE -2 Uint16
14-5* Environment 14-50 RFI 1 [1] On 1 set-up x FALSE - Uint8 14-52 Fan Control [0] Auto All set-ups TRUE - Uint8
14-53 Fan Monitor [1] Warning All set-ups TRUE - Uint8
14-55 Output Filter [0] No Filter 1 set-up FALSE - Uint8
14-56 Capacitance Output Filter 2.0 uF 1 set-up FALSE -7 Uint16
14-57 Inductance Output Filter 7.000 mH 1 set-up FALSE -6 Uint16 14-7* Compatibility 14-72 VLT Alarm Word 0 N/A All set-ups FALSE 0 Uint32 14-73 VLT Warning Word 0 N/A All set-ups FALSE 0 Uint32 14-74 VLT Ext. Status Word 0 N/A All set-ups FALSE 0 Uint32
4.3.13. 14-** Special Functions
4. How to Program
VLT
®
Automation Drive FC 300
Instruction Manual High Power
100 MG.33.U1.22 - VLT
®
is a registered Danfoss trademark.
4
