Danfoss VLT FC 300 User Manual

Par. No. #
Parameter description Default value 4-set-up FC 302
only
Change during
operation
Conver-
sion index
Type
15-0* Operating Data 15-00 Operating Hours 0 h All set-ups FALSE 74 Uint32 15-01 Running Hours 0 h All set-ups FALSE 74 Uint32
15-02 kWh Counter 0 kWh All set-ups FALSE 75 Uint32
15-03 Power-ups 0 N/A All set-ups FALSE 0 Uint32
15-04 Over Temps 0 N/A All set-ups FALSE 0 Uint16
15-05 Over Volts 0 N/A All set-ups FALSE 0 Uint16
15-06 Reset kWh Counter [0] Do not reset All set-ups TRUE - Uint8
15-07 Reset Running Hours Counter [0] Do not reset All set-ups TRUE - Uint8 15-1* Data Log Settings 15-10 Logging Source 0 2 set-ups TRUE - Uint16 15-11 Logging Interval ExpressionLimit 2 set-ups TRUE -3 TimD 15-12 Trigger Event [0] FALSE 1 set-up TRUE - Uint8
15-13 Logging Mode [0] Log always 2 set-ups TRUE - Uint8
15-14 Samples Before Trigger 50 N/A 2 set-ups TRUE 0 Uint8 15-2* Historic Log 15-20 Historic Log: Event 0 N/A All set-ups FALSE 0 Uint8 15-21 Historic Log: Value 0 N/A All set-ups FALSE 0 Uint32 15-22 Historic Log: Time 0 ms All set-ups FALSE -3 Uint32 15-3* Fault Log 15-30 Fault Log: Error Code 0 N/A All set-ups FALSE 0 Uint8 15-31 Fault Log: Value 0 N/A All set-ups FALSE 0 Int16 15-32 Fault Log: Time 0 s All set-ups FALSE 0 Uint32 15-4* Drive Identification 15-40 FC Type 0 N/A All set-ups FALSE 0 VisStr[6] 15-41 Power Section 0 N/A All set-ups FALSE 0 VisStr[20] 15-42 Voltage 0 N/A All set-ups FALSE 0 VisStr[20]
15-43 Software Version 0 N/A All set-ups FALSE 0 VisStr[5]
15-44 Ordered Typecode String 0 N/A All set-ups FALSE 0 VisStr[40]
15-45 Actual Typecode String 0 N/A All set-ups FALSE 0 VisStr[40]
15-46 Adj Freq Dr Ordering No. 0 N/A All set-ups FALSE 0 VisStr[8]
15-47 Power Card Ordering No. 0 N/A All set-ups FALSE 0 VisStr[8]
15-48 LCP ID Num. 0 N/A All set-ups FALSE 0 VisStr[20]
15-49 SW ID Control Card 0 N/A All set-ups FALSE 0 VisStr[20]
15-50 SW ID Power Card 0 N/A All set-ups FALSE 0 VisStr[20]
15-51 Adj Freq Dr Serial No. 0 N/A All set-ups FALSE 0 VisStr[10]
15-53 Power Card Serial Number 0 N/A All set-ups FALSE 0 VisStr[19]
4.3.14. 15-** Drive Information
VLT
®
Automation Drive FC 300
Instruction Manual High Power
4. How to Program
MG.33.U1.22 - VLT
®
is a registered Danfoss trademark. 101
4
