Danfoss VLT FC 300 - Page 120

380-500 Volt
VLT Type P250 P315 P355 P400
Max. Input Current [A] 400 472 590 590 647 647 733 684 787
Max. Input Current [A] 460/ 500 436 531 531 580 580 667 667 718
Max. external pre-fuses
1)
[A]
700 900 900 900
Soft Charge Fuses
2)
AC [A]
(qty)
20 (3)
SMPS fuse
3)
[A]
4
AC Fan fuse
3)
[A]
415
Supply Voltage [V] 3 Phase, 380-500 ± 10%
Supply Frequency [Hz] 50/ 60
Power Factor greater than 0.90
Efficiency 0.98
Power loss at rated max. load (400 V)
High Overload (150%) [W] 6005 6960 7691 7964
Normal Overload (110%) [W] 7630 7701 8879 9428
Enclosure
IP 00, IP 21/ NEMA 1 & IP 54/ NEMA 12
Vibration Test [g] 0.7
Relative Humidity [%] 93%, +2%, -3% (IEC 68-2-3)
Ambient Temperature
[degrees C]
-10° C to 40° C [14°-104° F] continuously, periodi-
cally at +45° C [113° F]
-25° C to +65°/70° C [-13°-149°/158° F] for stor-
age/ transport
Adjustable Frequency
Drive Protection
Ground and short-circuit protection
Weight
5)
IP 00/ Chassis [kg]
221.4 234.1 236.4 277.3
IP 21/ NEMA 1 [kg] 263.2 270.0 272.3 313.2
IP 54/ NEMA 12 [kg]
263.2 270.0 272.3 313.2
1) Bussman 170M6000 series. See fuse chart.
2) Bussmann FWH-20A6F or exact equivalent, 3 per unit
3) Bussmann KTK-4 or exact equivalent, 1 per unit
4) Littlefuse KLK-15 or exact equivalent, 1 per unit
5) VLT with standard input option, no brake, no load sharing
5. General Specifications
VLT
®
Automation Drive FC 300
Instruction Manual High Power
