Danfoss VLT FC 300 User Manual

525-690 Volt
VLT Type P110 P132 P160
Output current [VAC] HO NO HO NO HO NO
Continuous (100/ 100%) [A] 550 137 162 162 201 201 253
Intermittent (150/ 110%) [A] 550 206 178 243 221 302 278
Continuous (100/ 100%) [A] 575/ 690 131 155 155 192 192 242
Intermittent (150/ 110%) [A] 575/ 690 197 171 233 211 288 266
Output kVA
Continuous (100/ 100%) [kVA] 550 131 154 154 191 191 241
Intermittent (150/ 110%) [kVA] 550 196 170 231 211 287 265
Continuous (100/ 100%) [kVA] 575 130 154 154 191 191 241
Intermittent (150/ 110%) [kVA] 575 196 170 232 210 287 265
Continuous (100/ 100%) [kVA] 690 157 185 185 229 229 289
Intermittent (150/ 110%) [kVA] 690 235 204 278 252 344 318
Typical Shaft Output
High Overload (150%) [kW] 550 90 110 132
Normal Overload (110%) [kW] 550 110 132 160
High Overload (150%) [HP] 575 125 150 200
Normal Overload (110%) [HP] 575 150 200 250
High Overload (150%) [kW] 690 110 132 160
Normal Overload (110%) [kW] 690 132 160 200
Max. Motor Cable Length 500 ft (150 m) shielded, 1,000 ft (300
m) unshielded
Output Voltage [%] 0-100% of the AC line voltage
Output Frequency [Hz] 0-200
Rated Motor Voltage [V] 550/ 575/ 690
Rated Motor Frequency [Hz] 50/60
Thermal protection during opera-
tion
ETR for motor (Class 20)
Thermal protection during opera-
tion
85 90 110
Switching on the Output Unlimited
Ramp times [sec] 0.01 - 3600
VLT
®
Automation Drive FC 300
Instruction Manual High Power
5. General Specifications
MG.33.U1.22 - VLT
®
is a registered Danfoss trademark. 121
5
