Danfoss VLT FC 300 User Manual

Par. No. #
Parameter description Default value 4-set-up FC 302
only
Change during
operation
Conver-
sion index
Type
3-0* Reference Limits 3-00 Reference Range null All set-ups TRUE - Uint8 3-01 Reference/Feedback Unit null All set-ups TRUE - Uint8
3-02 Minimum Reference 0 ReferenceFeedbackUnit All set-ups TRUE -3 Int32
3-03 Maximum Reference ExpressionLimit All set-ups TRUE -3 Int32
3-04
Reference Function [0] Sum All set-ups TRUE - Uint8
3-1* References 3-10 Preset Reference 0.00 % All set-ups TRUE -2 Int16 3-11 Jog Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
3-12 Catch up/slow-down Value 0.00 % All set-ups TRUE -2 Int16
3-13 Reference Site [0] Linked to Hand / Auto All set-ups TRUE - Uint8
3-14 Preset Relative Reference 0.00 % All set-ups TRUE -2 Int32
3-15 Reference Resource 1 null All set-ups TRUE - Uint8
3-16 Reference Resource 2 null All set-ups TRUE - Uint8
3-17 Reference Resource 3 null All set-ups TRUE - Uint8
3-18 Relative Scaling Reference Resource [0] No function All set-ups TRUE - Uint8
3-19 Jog Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16 3-4* Ramp 1 3-40 Ramp 1 Type [0] Linear All set-ups TRUE - Uint8 3-41 Ramp 1 Ramp-up Time ExpressionLimit All set-ups TRUE -2 Uint32 3-42 Ramp 1 Ramp-down Time ExpressionLimit All set-ups TRUE -2 Uint32
3-45 Ramp 1 S-ramp Ratio at Accel. Start 50 % All set-ups TRUE 0 Uint8
3-46 Ramp 1 S-ramp Ratio at Accel. End 50 % All set-ups TRUE 0 Uint8
3-47 Ramp 1 S-ramp Ratio at Decel. Start 50 % All set-ups TRUE 0 Uint8
3-48 Ramp 1 S-ramp Ratio at Decel. End 50 % All set-ups TRUE 0 Uint8 3-5* Ramp 2 3-50 Ramp 2 Type [0] Linear All set-ups TRUE - Uint8 3-51 Ramp 2 Ramp-up Time ExpressionLimit All set-ups TRUE -2 Uint32 3-52 Ramp 2 Ramp-down Time ExpressionLimit All set-ups TRUE -2 Uint32
3-55 Ramp 2 S-ramp Ratio at Accel. Start 50 % All set-ups TRUE 0 Uint8
3-56 Ramp 2 S-ramp Ratio at Accel. End 50 % All set-ups TRUE 0 Uint8
3-57 Ramp 2 S-ramp Ratio at Decel. Start 50 % All set-ups TRUE 0 Uint8
3-58 Ramp 2 S-ramp Ratio at Decel. End 50 % All set-ups TRUE 0 Uint8
4.3.4. 3-** Reference / Ramps
VLT
®
Automation Drive FC 300
Instruction Manual High Power
4. How to Program
MG.33.U1.22 - VLT
®
is a registered Danfoss trademark. 89
4
