Danfoss VLT FC 300 User Manual

Par. No. #
Parameter description Default value 4 set-up FC 302
only
Change during
operation
Conver-
sion index
Type
3-6* Ramp 3 3-60 Ramp 3 Type [0] Linear All set-ups TRUE - Uint8 3-61 Ramp 3 Ramp-up Time ExpressionLimit All set-ups TRUE -2 Uint32
3-62 Ramp 3 Ramp-down Time ExpressionLimit All set-ups TRUE -2 Uint32
3-65 Ramp 3 S-ramp Ratio at Accel. Start 50 % All set-ups TRUE 0 Uint8
3-66 Ramp 3 S-ramp Ratio at Accel. End 50 % All set-ups TRUE 0 Uint8
3-67 Ramp 3 S-ramp Ratio at Decel. Start 50 % All set-ups TRUE 0 Uint8
3-68
Ramp 3 S-ramp Ratio at Decel. End 50 % All set-ups TRUE 0 Uint8
3-7* Ramp 4 3-70 Ramp 4 Type [0] Linear All set-ups TRUE - Uint8 3-71 Ramp 4 Ramp-up Time ExpressionLimit All set-ups TRUE -2 Uint32
3-72 Ramp 4 Ramp-down Time ExpressionLimit All set-ups TRUE -2 Uint32
3-75 Ramp 4 S-ramp Ratio at Accel. Start 50 % All set-ups TRUE 0 Uint8
3-76 Ramp 4 S-ramp Ratio at Accel. End 50 % All set-ups TRUE 0 Uint8
3-77 Ramp 4 S-ramp Ratio at Decel. Start 50 % All set-ups TRUE 0 Uint8
3-78
Ramp 4 S-ramp Ratio at Decel. End 50 % All set-ups TRUE 0 Uint8
3-8* Other Ramps 3-80 Jog Ramp Time ExpressionLimit All set-ups TRUE -2 Uint32 3-81 Quick Stop Ramp Time ExpressionLimit 2 set-ups TRUE -2 Uint32 3-9 * Digital Potentiometer 3-90 Step Size 0.10 % All set-ups TRUE -2 Uint16 3-91 Ramp Time 1.00 s All set-ups TRUE -2 Uint32 3-92 Power Restore [0] Off All set-ups TRUE - Uint8
3-93 Maximum Limit 100 % All set-ups TRUE 0 Int16
3-94 Minimum Limit -100 % All set-ups TRUE 0 Int16
3-95 Ramp Delay 1.000 N/A All set-ups TRUE -3 TimD
4. How to Program
VLT
®
Automation Drive FC 300
Instruction Manual High Power
90 MG.33.U1.22 - VLT
®
is a registered Danfoss trademark.
4
