Danfoss VLT FC 300 User Manual

Par. No. #
Parameter description Default value 4-set-up FC 302
only
Change during
operation
Conver-
sion index
Type
4-1* Motor Limits 4-10 Motor Speed Direction null All set-ups FALSE - Uint8 4-11 Motor Speed Low Limit [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
4-12 Motor Speed Low Limit [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
4-13 Motor Speed High Limit [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
4-14 Motor Speed High Limit [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
4-16 Torque Limit Motor Mode ExpressionLimit All set-ups TRUE -1 Uint16
4-17 Torque Limit Generator Mode 100.0 % All set-ups TRUE -1 Uint16
4-18 Current Limit ExpressionLimit All set-ups TRUE -1 Uint32
4-19
Max Output Frequency 132.0 Hz All set-ups FALSE -1 Uint16
4-2* Limit Factors 4-20 Torque Limit Factor Source [0] No function All set-ups TRUE - Uint8 4-21 Speed Limit Factor Source [0] No function All set-ups TRUE - Uint8 4-3* Motor Fb Monitor 4-30 Motor Feedback Loss Function [2] Trip All set-ups TRUE - Uint8 4-31 Motor Feedback Speed Error 300 RPM All set-ups TRUE 67 Uint16 4-32 Motor Feedback Loss Timeout 0.05 s All set-ups TRUE -2 Uint16 4-5* Adj. Warnings 4-50 Warning Current Low 0.00 A All set-ups TRUE -2 Uint32 4-51 Warning Current High ImaxVLT (P1637) All set-ups TRUE -2 Uint32 4-52 Warning Speed Low 0 RPM All set-ups TRUE 67 Uint16
4-53 Warning Speed High outputSpeedHighLimit (P413) All set-ups TRUE 67 Uint16
4-54 Warning Reference Low -999999.999 N/A All set-ups TRUE -3 Int32
4-55 Warning Reference High 999999.999 N/A All set-ups TRUE -3 Int32
4-56 Warning Feedback Low -999999.999 ReferenceFeedbackUnit All set-ups TRUE -3 Int32
4-57 Warning Feedback High 999999.999 ReferenceFeedbackUnit All set-ups TRUE -3 Int32
4-58 Missing Motor Phase Function [1] On All set-ups TRUE - Uint8 4-6* Speed Bypass 4-60 Bypass Speed From [RPM] ExpressionLimit All set-ups TRUE 67 Uint16 4-61 Bypass Speed From [Hz] ExpressionLimit All set-ups TRUE -1 Uint16 4-62 Bypass Speed to [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
4-63 Bypass Speed To [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
4.3.5. 4-** Limits / Warnings
VLT
®
Automation Drive FC 300
Instruction Manual High Power
4. How to Program
MG.33.U1.22 - VLT
®
is a registered Danfoss trademark. 91
4
