Danfoss VLT FC Series Installation Guide

Table 3: Discharge Time, VLT® AQUA Drive FC 202
Voltage [V] Minimum waiting time (minutes)
4 7 15 20 30 40
200–240 0.25–3.7 kW
(0.34–5 hp)
– 5.5–37 kW
(7.5–50 hp)
– – –
380–480 0.25–7.5 kW
(0.34–10 hp)
– 11–75 kW
(15–100 hp)
110–315 kW
(150–450 hp)
– 315–1000 kW
(450–1350 hp)
355–560 kW
(500–750 hp)
525–600 0.75–7.5 kW
(1–10 hp)
– 11–90 kW
(15–121 hp)
– 400–1400 kW
(400–1550 hp)
–
525–690 – 1.1–7.5 kW
(1.5–10 hp)
11–90 kW
(10–100 hp)
75–400 kW
(75–400 hp)
– 450–800 kW
(450–950 hp)
Table 4: Discharge Time, VLT® AutomationDrive FC 301/FC 302
Voltage [V] Minimum waiting time (minutes)
4 7 15 20 30 40
200–240 0.25–3.7 kW
(0.34–5 hp)
– 5.5–37 kW
(7.5–50 hp)
– – –
380–500 0.25–7.5 kW
(0.34–10 hp)
– 11–75 kW
(15–100 hp)
90–200 kW
(150–350 hp)
250–500 kW
(450–750 hp)
250–800 kW
(450–1350 hp)
315–500 kW
(500–750 hp)
400 – – – 90–315 kW
(125–450 hp)
– –
500 – – – 110–355 kW
(150–450 hp)
– –
525 – – – 55–315 kW
(75–400 hp)
– –
525–600 0.75–7.5 kW
(1–10 hp)
– 11–75 kW
(15–100 hp)
– – –
Introduction
Installation Guide | Control Card VLT® FC Series
AN279051429263en-000101 / 130R0788 | 3
Danfoss A/S © 2018.09
