Illustration 4: Removing the LCP Cradle
3. Remove all control cables from the metal bracket (spring-loaded).
4. Remove any A, B, or C options that may be installed.
5. Remove the I/O terminals.
1
2
3
e30bf721.12
1 Location of A option
3 I/O terminals
2 Location of B option
Illustration 5: Location of Options and I/O Terminals
6. Unscrew the 3 T10 screws and remove the cable shield.
7. Remove the plastic cover underneath the cable shield.
Replacement
Installation Guide | Control Card VLT® FC Series
AN279051429263en-000101 / 130R0788 | 7
Danfoss A/S © 2018.09
