Installation
NOTICE
The VLT
®
Wireless Communication Panel LCP 103 is hot-
pluggable and can be connected when the drive is powered
on.
1. Mount the LCP 103 in the LCP input plug on the
drive.
2.
Search for MyDrive
®
Connect in Google Play or Apple
Store.
Illustration 1.2 MyDrive
®
Connect Launch Icon
3.
Download and install the MyDrive
®
Connect App.
NOTICE
Start pairing within the rst 10 minutes after the instal-
lation. Failing to do so closes the broadcast or wireless
identication
due to security limits with default passwords.
To reconnect, power cycle the drive, or remove and
reconnect the LCP 103.
Connection Procedure
NOTICE
The wireless SSID is the Danfoss serial ID of the drive. For
example, Danfoss_019223G455 is the default wireless SSID
for a drive with the serial number 019223G455. The serial
number is on the product nameplate, but is also visible in
parameter 15-51 Frequency Converter Serial Number.
Wireless SSID Danfoss_019223G455
Default password Danfoss1933
1. Open the app and establish the Wi-Fi connection, see
Table 1.1 for descriptions of the white Wi-Fi LED.
2. When prompted, change the default password due to
security restrictions. The password must be at least 8
and maximum 48 characters.
3. Re-plug the LCP 103 for the password to change into
eect.
Failing to do so allows the LCP 103 to keep
broadcasting.
4. Disconnect the app, navigate to smart device
settings, and forget the network.
5. Search for the wireless network and connect with the
new password.
NOTICE
If the password is not changed, it leaves only 10 minutes for
connecting and performing Drive operations. After this, the
wireless connection closes.
Reset password
If the wireless SSID and password are forgotten, access
parameter group 30-9* Wi LCP via MCT 10 Set-up Software or
LCP 102.
LED Pattern
LED Pattern Description
On Solid
green
The drive is powered on (normal operation).
Wi-Fi
Flashing
white
Connection pairing successful.
Solid
white
The smart device is connected and communi-
cation is OK.
Alarm Flashing
red
An alarm has occurred.
Warn Solid
yellow
A warning has occurred.
MS,
NS1,
NS2
1)
Flashing
orange
Identication of the drive when initiated through
a winking command.
Flashing
orange
Incompatible drive (LED ashes 3 times and then
remains on).
Table 1.1 Descriptions, LED Indicators
1) MS=module status, NS1=network status 1, NS2=Network status 2.
Safe Control
The safe control parameter allows the drive to decide the
motor behavior if the smart device, for example a tablet,
communication is lost. If the limits are set to [1] Stop motor,
the motor stops. If the limits are set to [0] Do nothing, the
motor continues to run. This is only applicable when the
motor is in Run state and if the motor has been started from
the app.
The communication happens between the MyDrive
®
Connect
App and the VLT
®
Wireless Communication Panel LCP 103.
Parameter Limits/options
Parameter 30-97 Wi Timeout Action [0] Do nothing
[1] Stop motor
Installation Instructions
VLT
®
Wireless Communication Panel LCP 103
VLT
®
FC Series FC 102, FC 103, FC 202,
FC 301/FC 302, and LD 302
2
Danfoss A/S © 08/2018 All rights reserved. MI38V402
