[27] Logic rule 1 Use the result of logic rule 1 in the logic rule.
[28] Logic rule 2 Use the result of logic rule 2 in the logic rule.
[29] Logic rule 3 Use the result of logic rule 3 in the logic rule.
[33] Digital input DI18 Use the value of DI18 in the logic rule (High = TRUE).
[34] Digital input DI19 Use the value of DI19 in the logic rule (High = TRUE).
[35] Digital input DI27 Use the value of DI27 in the logic rule (High = TRUE).
[36] Digital input DI29 Use the value of DI29 in the logic rule (High = TRUE).
[37] Digital input DI32 Use the value of DI32 in the logic rule (High = TRUE).
[38] Digital input DI33 Use the value of DI33 in the logic rule (High = TRUE).
[39] Start command This event is TRUE if the adjustable frequency drive is started by any means (either via digital input,
serial communication bus or other).
[40] Drive stopped This event is TRUE if the adjustable frequency drive is stopped or coasted by any means (either via
digital input, serial communication bus or other).
[41] Reset Trip This event is TRUE if the adjustable frequency drive is tripped (but not trip-locked) and the reset
button is pressed.
[42] Auto Reset Trip This event is TRUE if the adjustable frequency drive is tripped (but not trip-locked) and an automatic
reset is issued.
[43] OK Key This event is TRUE if the OK key on the LCP is pressed.
[44] Reset Key This event is TRUE if the Reset key on the LCP is pressed.
[45] Left Key This event is TRUE if the Left key on the LCP is pressed.
[46] Right Key This event is TRUE if the Right key on the LCP is pressed.
[47] Up Key This event is TRUE if the Up key on the LCP is pressed.
[48] Down Key This event is TRUE if the Down key on the LCP is pressed.
[50] Comparator 4 Use the result of comparator 4 in the logic rule.
[51] Comparator 5 Use the result of comparator 5 in the logic rule.
[60] Logic rule 4 Use the result of logic rule 4 in the logic rule.
[61] Logic rule 5 Use the result of logic rule 5 in the logic rule.
13-02 Stop Event
Option: Function:
Select the Boolean (TRUE or FALSE) input to deactivate Smart Logic Control.
[0] * FALSE Enters the fixed value of FALSE in the logic rule.
[1] TRUE Enters the fixed value TRUE in the logic rule.
[2] Running See parameter group 5-3* for further description.
[3] In range See parameter group 5-3* for further description.
[4] On reference See parameter group 5-3* for further description.
[5] Torque limit See parameter group 5-3* for further description.
[6] Current limit See parameter group 5-3* for further description.
3 Parameter Description VLT
®
HVAC Drive Programming Guide
3-120 MG.11.C6.22 - VLT
®
is a registered Danfoss trademark
3
