Danfoss VLT HVAC Series User Manual

18-32 Analog Input X42/5
Range: Function:
0.000 N/A* [-20.000 - 20.000 N/A] Readout of the value of the signal applied to terminal X42/5 on the Analog I/O Card.
The units of the value shown in the LCP will correspond to the mode selected in par.26-02
Terminal
X42/5 Mode
.
18-33 Analog Out X42/7 [V]
Range: Function:
0.000 N/A* [0.000 - 30.000 N/A] Readout of the value of the signal applied to terminal X42/7 on the Analog I/O Card.
The value shown reflects the selection in par.26-40
Terminal X42/7 Output .
18-34 Analog Out X42/9 [V]
Range: Function:
0.000 N/A* [0.000 - 30.000 N/A] Readout of the value of the signal applied to terminal X42/9 on the Analog I/O Card.
The value shown reflects the selection in par.26-50
Terminal X42/9 Output .
18-35 Analog Out X42/11 [V]
Range: Function:
0.000 N/A* [0.000 - 30.000 N/A] Readout of the value of the signal applied to terminal X42/11 on the Analog I/O Card.
The value shown reflects the selection in par.26-60
Terminal X42/11 Output .
3 Parameter Description VLT
®
HVAC Drive Programming Guide
3-164 MG.11.C6.22 - VLT
®
is a registered Danfoss trademark
3

Danfoss VLT HVAC Series Specifications

General

Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Communication Interfaces	Profibus, Ethernet
Cooling Method	Forced convection
Ambient Temperature	-10°C to +40°C
Enclosure Rating	IP20, IP21, IP55
Output Voltage	0 - 100% of supply voltage
