26-43 Terminal X42/7 Output Bus Control
Range: Function:
0.00 %* [0.00 - 100.00 %] Holds the level of terminal X42/7 if controlled by the bus.
26-44 Terminal X42/7 Output Timeout Preset
Range: Function:
0.00 %* [0.00 - 100.00 %] Holds the preset level of terminal X42/7.
In case of a bus timeout and a timeout function is selected in par.26-50
Terminal X42/9 Output , the
output will preset to this level.
26-50 Terminal X42/9 Output
Option: Function:
Set the function of terminal X42/9.
[0] * No operation
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor current
[104] Torque rel to limit
[105] Torq relate to rated
[106] Power
[107] Speed
[113] Ext. Closed-loop 1
[114] Ext. Closed-loop 2
[115] Ext. Closed-loop 3
[139] Bus ctrl.
[141] Bus ctrl t.o.
26-51 Terminal X42/9 Min. Scale
Range: Function:
0.00 %* [0.00 - 200.00 %] Scale the minimum output of the selected analog signal at terminal X42/9, as a percentage of the
maximum signal level, for example if a 0 V is desired at 25% of the maximum output value. Then
program 25%. Scaling values up to 100% can never be higher than the corresponding setting in
par.26-52
Terminal X42/9 Max. Scale .
See principle graph for par.6-51
Terminal 42 Output Min Scale .
3 Parameter Description VLT
®
HVAC Drive Programming Guide
3-256 MG.11.C6.22 - VLT
®
is a registered Danfoss trademark
3

Danfoss VLT HVAC Series Specifications

General

Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Communication Interfaces	Profibus, Ethernet
Cooling Method	Forced convection
Ambient Temperature	-10°C to +40°C
Enclosure Rating	IP20, IP21, IP55
Output Voltage	0 - 100% of supply voltage
