Danfoss VLT HVAC Series User Manual

23-61 Continuous Bin Data
Range: Function:
0 N/A* [0 - 4294967295 N/A] Array with 10 elements ([0]-[9] below parameter number in display). Press OK and step between
elements by means of
▲
and
▼
buttons on the LCP.
10 counters with the frequency of occurrence for the operating variable monitored, sorted according
to the following intervals:
Counter [0]: 0%–<10%
Counter [1]: 10%–<20%
Counter [2]: 20%–<30%
Counter [3]: 30%–<40%
Counter [4]: 40%–<50%
Counter [5]: 50%–<60%
Counter [6]: 60%–<70%
Counter [7]: 70%–<80%
Counter [8]: 80%–<90%
Counter [9]: 90%–<100% or Max
The above minimum limits for the intervals are the default limits. These can be changed in par.
23-65
Minimum Bin Value .
Starts to count when the adjustable frequency drive is powered up for the first time. All counters
can be reset to 0 in par.23-66
Reset Continuous Bin Data .
23-62 Timed Bin Data
Range: Function:
0 N/A* [0 - 4294967295 N/A] Array with 10 elements ([0]-[9] below parameter number in display). Press OK and step between
elements by means of
▲
and
▼
buttons on the LCP.
10 counters with the frequency of occurrence for the operating data monitored sorted according to
the intervals as for par.23-61
Continuous Bin Data .
Starts to count at the date/time programmed in par.23-63
Timed Period Start , and stops at the time/
date programmed in par.23-64
Timed Period Stop . All counters can be reset to 0 in par.23-67 Reset
Timed Bin Data
.
23-63 Timed Period Start
Range: Function:
0 N/A* [0 - 0 N/A] Set the date and time at which trending starts the update of the timed bin counters.
Date format will depend on setting in par.0-71
Date Format , and time format on setting in par.
0-72
Time Format .
NOTE!
The adjustable frequency drive has no back-up of the clock function and the set date/time will reset to default (2000-01-01 00:00)
after a power-down unless a Real Time Clock module with back-up is installed. Consequently, logging will be stopped until the date/
time is readjusted in par.0-70
Set Date and Time . In par.0-79 Clock Fault , it is possible to program for a warning in case the clock has
not been set properly, e.g., after a power-down.
3 Parameter Description VLT
®
HVAC Drive Programming Guide
3-224 MG.11.C6.22 - VLT
®
is a registered Danfoss trademark
3

Danfoss VLT HVAC Series Specifications

General

Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Communication Interfaces	Profibus, Ethernet
Cooling Method	Forced convection
Ambient Temperature	-10°C to +40°C
Enclosure Rating	IP20, IP21, IP55
Output Voltage	0 - 100% of supply voltage
