Danfoss VLT HVAC Series

[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lbs / sec.
[131] lbs / min.
[132] lbs / hr.
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in. wtr. gage
[173] ft WG
[174] in Hg
[180] HP
24-03 Fire Mode Min Reference
Range: Function:
0 FireMo-
deUnit*
[-999999.999 - par. 24-04 FireMo-
deUnit]
Minimum value for the reference/setpoint (limiting the sum of value in par.24-05 Fire Mode Preset
Reference
and value of signal on input selected in par.24-06 Fire Mode Reference Source ).
If running in open-loop when fire mode is active, the unit is chosen by the setting of par.0-02
Motor
Speed Unit
. For closed-loop, the unit is selected in par.24-02 Fire Mode Unit .
24-04 Fire Mode Max Reference
Range: Function:
50.000 Fire-
ModeUnit*
[par. 24-03 - 999999.999 FireMo-
deUnit]
Maximum value for the reference/setpoint (limiting the sum of value in par.24-05 Fire Mode Preset
Reference
and value of signal on input selected in par.24-06 Fire Mode Reference Source ).
If running in open-loop when fire mode is active, the unit is chosen by the setting of par.0-02
Motor
Speed Unit
. For closed-loop, the unit is selected in par.24-02 Fire Mode Unit .
24-05 Fire Mode Preset Reference
Range: Function:
0.00 %* [-100.00 - 100.00 %] Enter the required preset reference/setpoint as a percentage of the Fire Mode Max Reference set
in par.24-04
Fire Mode Max Reference . The set value will be added to the value represented by the
signal on the analog input selected in
par.24-06 Fire Mode Reference Source, Fire Mode Reference
Source
.
VLT
®
HVAC Drive Programming Guide 3 Parameter Description
MG.11.C6.22 - VLT
®
is a registered Danfoss trademark 3-231
3
