Danfoss VLT HVAC Series User Manual

0-31 Custom Readout Min Value
Range: Function:
0.00 Cus-
tomReadou-
tUnit*
[0.00 - 100.00 CustomReadoutUnit] This parameter allows the choice of the min. value of the custom defined readout (occurs at zero
speed). It is only possible to select a value different to 0 when selecting a linear unit in par.
0-30
Custom Readout Unit . For quadratic and cubic units, the minimum value will be 0.
0-32 Custom Readout Max Value
Range: Function:
100.00 Cus-
tomReadou-
tUnit*
[par. 0-31 - 999999.99 CustomRea-
doutUnit]
This parameter sets the max value to be shown when the speed of the motor has reached the set
value for (par.4-13
Motor Speed High Limit [RPM] and par.4-14 Motor Speed High Limit [Hz] ).
0-37 Display Text 1
Range: Function:
0 N/A* [0 - 0 N/A] In this parameter, it is possible to write an individual text string for display in the LCP or to be read
via serial communication. If it is to be displayed permanently, select Display Text 1 in par.
0-20
Display Line 1.1 Small , par. 0-21 Display Line 1.2 Small , par. 0-22 Display Line 1.3 Small ,
par. 0-23
Display Line 2 Large or par. 0-24 Display Line 3 Large . Use the
▲
or
▼
buttons on the
LCP to change a character. Use the
◀
and
▶
buttons to move the cursor. When a character is
highlighted by the cursor, it can be changed. Use the
▲
or
▼
buttons on the LCP to change a
character. A character can be inserted by placing the cursor between two characters and pressing
▲
or
▼
.
0-38 Display Text 2
Range: Function:
0 N/A* [0 - 0 N/A] In this parameter, it is possible to write an individual text string for display in the LCP or to be read
via serial communication. If it is to be displayed permanently, select Display Text 2 in par.
0-20
Display Line 1.1 Small , par. 0-21 Display Line 1.2 Small , par. 0-22 Display Line 1.3 Small ,
par. 0-23
Display Line 2 Large or par. 0-24 Display Line 3 Large . Use the
▲
or
▼
buttons on the
LCP to change a character. Use the
◀
and
▶
buttons to move the cursor. When a character is
highlighted by the cursor, this character can be changed. A character can be inserted by placing the
cursor between two characters and pressing
▲
or
▼
.
0-39 Display Text 3
Range: Function:
0 N/A* [0 - 0 N/A] In this parameter, it is possible to write an individual text string for display in the LCP or to be read
via serial communication. If it is to be displayed permanently, select Display Text 3 in par.
0-20
Display Line 1.1 Small ,par. 0-21 Display Line 1.2 Small , par. 0-22 Display Line 1.3 Small ,
par. 0-23
Display Line 2 Large or par. 0-24 Display Line 3 Large . Use the
▲
or
▼
buttons on the
LCP to change a character. Use the
◀
and
▶
buttons to move the cursor. When a character is
highlighted by the cursor, this character can be changed. A character can be inserted by placing the
cursor between two characters and pressing
▲
or
▼
.
VLT
®
HVAC Drive Programming Guide 3 Parameter Description
MG.11.C6.22 - VLT
®
is a registered Danfoss trademark 3-13
3

Danfoss VLT HVAC Series Specifications

General

Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Communication Interfaces	Profibus, Ethernet
Cooling Method	Forced convection
Ambient Temperature	-10°C to +40°C
Enclosure Rating	IP20, IP21, IP55
Output Voltage	0 - 100% of supply voltage
