• Simple and accurate documentation of frequency converter settings after commissioning.
• Expanding an existing network
• Future developed frequency converters will be supported
MCT 10 Set-up Software supports Profibus DP-V1 via a Master class 2 connection. It makes it
possible to on line read/write parameters in a frequency converter via the Profibus network. This
will eliminate the need for an extra communication network.
Save Frequency Converter Settings:
1. Connect a PC to the unit via USB com port. (Note: Use a PC, which is isolated from the
mains, in conjunction with the USB port. Failure to do so may damage equipment.)
2. Open MCT 10 Set-up Software
3. Choose “Read from drive”
4. Choose “Save as”
All parameters are now stored in the PC.
Load Frequency Converter Settings:
1. Connect a PC to the frequency converter via USB com port
2. Open MCT 10 Set-up software
3. Choose “Open”– stored files will be shown
4. Open the appropriate file
5. Choose “Write to drive”
All parameter settings are now transferred to the frequency converter.
A separate manual for MCT 10 Set-up Software is available: MG.10.R2.02.
The MCT 10 Set-up Software Modules
The following modules are included in the software package:
MCT 10 Set-up Software
Setting parameters
Copy to and from frequency converters
Documentation and print out of parameter settings incl. diagrams
Ext. User Interface
Preventive Maintenance Schedule
Clock settings
Timed Action Programming
Smart Logic Controller Set-up
Ordering number:
Please order the CD containing MCT 10 Set-up Software using code number 130B1000.
MCT 10 can also be downloaded from the Danfoss Internet: WWW.DANFOSS.COM, Business Area:
Motion Controls.
VLT
®
HVAC Drive Operating Instructions 5. How to operate the frequency converter
MG.11.A4.02 - 09.10.06. VLT
®
is a registered Danfoss trademark
51
5
