Page #153 background imageLoading...
Page #153 background image
151
060783 Version 1.3 07.10.2011
Caractéristiques techniques
Caractéristiques de
performance
Le tableau suivant indique les caractéristiques de performance pour un modèle HCV 3
et HCV 5.
Spécifications
Appareil
HCV 3
HCV 5
Volume d'air max., circulation libre
(m
3
/h)
330
520
Échangeur de chaleur
Dantherm Alu. Échangeur méthodique
Efficacité thermique
%
Jusqu'à 95
1
Filtre à air d'alimentation/d'échappe-
ment, standard
G4/G4
Plage de températures de
fonctionnement sans préchauffage
°C
÷13
2
à +50
Plage de températures de
fonctionnement avec préchauffage
°C
-30 à +50
Caractéristiques de
l'armoire
Le tableau suivant indique les caractéristiques techniques de l'armoire pour un modèle
HCV 3 et HCV 5.
Spécifications
Appareil
HCV 3
HCV 5
Hauteur
mm
1005
1055
Largeur
mm
530
590
Profondeur (montage sur rail
standard/rail pour montage sur plan)
mm
434/419
584/569
Raccordement de la conduite
mm
125
160
Poids, appareil
kg
33
45
Poids emballage inclus
kg
43
57
Dimensions emballage inclus
(H x L x P)
mm
H : 654
L : 1076
P : 435
H : 723
L : 1124
P : 600
Matériau externe de l'armoire
Aluzinc
Couleur
RAL
9010
Isolation de l'armoire, styrène
mm
32
Facteur d'isolation, armoire
L/m
2
x °K
0,97
Classification incendie, armoire en
polystyrène
DIN 4102, classe B1
Classification incendie, appareil compl.
EN 13501, classe E
Classe de protection
IP
20
Suite à la page suivante
1
Opération de condensation.
2
Dantherm Air Handling recommande le préchauffage à des températures inférieures à afin de garantir un
fonctionnement équilibré.-6°C
