060783 • Version 1.3 • 26.04.2011
Introduction
Overview
Introduction This is the installation and service guide for the home ventilation units
HCV 3 and HCV 5 from Dantherm Air Handling. The table of contents below lists the
sections in this guide.
Serial number For any future inquiries regarding e.g. spare parts we kindly ask you to make a note of
the serial numbers of the units here: ______________________
This guide covers units with serial numbers higher than: xxxxxx1128910
Warning
The ducting system must not be mounted until the unit is ready to operate. The power
must not be connected until the ducting system has been mounted.
The ventilation unit should not be used to dry newly built houses during construction or
immediately after construction.
The ducts must be dimmed and the units must not be connected until the house is
ready for occupation, which means that the house is clean and dry. This is to prevent
any construction dust and condensed water from depositing in the ducting system and
to prevent any sanitation inconveniences from the ventilation units later on.
If above mentioned warnings are disrespected, the warranty of the unit will be annulled
and any kind of maintenance will be done at the customers own expense.
Table of contents
This guide covers the following sections
Topic See page
General information 42
Product description 43
Fittings and installations 45
How to balance the unit 49
Set points and control strategies 53
Preventive maintenance 55
List of spare parts, HCV 3 59
List of spare parts, HCV 5 61
Fault finding instruction 63
Service agreement 67
Technical data 68
Dimensions, HCV 3 70
Dimensions, HCV 5 71
Wiring diagram 72
Appendix A – Performance and specific fan effect 74
Index 78
