Dantherm HCV 3 Installation And Service Guide

68
Technical data
Performance data
The table shows the technical performance data for HCV 3 and HCV 5.
Specification Unit HCV 3 HCV 5
Max. air volume, free blowing (m
3
/h) 330 520
Heat exchanger Dantherm Alu. Counterflow Heat Exchanger
Temperature efficiency % Up to 95
1
Filter class supply air/exhaust, stan-
dard
G4/G4
Operational temperature range with-
out pre-heat
°C ÷13
2
to + 50
Operational temperature range with
pre-heat
°C ÷ 30 to + 50
Cabinet data
The table shows the technical cabinet data for HCV 3 and HCV 5.
Specification unit HCV 3 HCV 5
Height mm 1005 1055
Width mm 530 590
Depth (Standard mounting rail/rail for
plan mounting)
mm 434/419 584/569
Duct connection mm 125 160
Weight, unit kg 33 45
Weight including packaging kg 43 57
Dimensions including packaging
(HxWxD)
mm H: 654
W: 1076
D: 435
H: 723
W: 1124
D: 600
Outer cabinet material Aluzink
Colour RAL 9010
Cabinet insulation, styrene mm 32
Insulation factor, cabinet W/m
2
x °K 0,97
Fire classification, polystyrene cabi-
net
DIN 4102 class B1
Fire class, the whole unit EN 13501 class E
Protection class IP 20
Continued overleaf
1
Condensing operation.
2
Dantherm Air Handling recommends preheating at temperatures under -6°C to ensure a balanced opera-
tion.
