Dantherm HCV 3 Installation And Service Guide

69
060783 • Version 1.3 • 26.04.2011
Technical data, continued
Electrical data
The table shows the technical electrical data for HCV 3 and HCV 5.
Specification Unit HCV 3 HCV 5
Integrated control panel HCP 4 in
front cover
- Yes
Supply voltage 1x230 V, 50 Hz
Max. current consumption, w/o pre-
heat and afterheat
A 0,4 0,7
Max. power consumption, w/o pre-
heat and afterheat
W 88 154
Cabinet, sound
data
The table shows the technical sound data for HCV 3 and HCV 5.
Specification Unit HCV 3 HCV 5
m
3
/h 140 220
External pressure Pa 70 100 70 100
Sound power level, cabinet Lw dB(A) 51 53 54 56
Sound pressure, cabinet at 1 metre
3
Lp dB(A) 47 49 50 52
Duct, sound data
The table shows the technical sound data for HCV 3 and HCV 5.
Specification unit HCV 3 HCV 5
63 Hz (supply/extract) Lw dB(A) 34/35 36/37 37/38 38/39
125 Hz (supply/extract) Lw dB(A) 40/38 42/40 42/41 44/43
250 Hz (supply/extract) Lw dB(A) 43/40 45/43 53/50 55/52
500 Hz (supply/extract) Lw dB(A) 44/44 47/47 42/42 45/45
1000 Hz (supply/extract) Lw dB(A) 36/41 38/43 41/36 43/38
2000 Hz (supply/extract) Lw dB(A) 27/33 29/33 39/34 40/35
4000 Hz (supply/extract) Lw dB(A) 19/24 21/26 27/20 29/22
Sound power level, supply air duct Lw dB(A) 57 59 57 59
Sound power level, extract air duct Lw dB(A) 56 58 56 58
Sound pressure, supply air duct,
1 metre
2
Lp dB(A) 43 45 43 45
Sound pressure, extract air duct,
1 metre
2
Lp dB(A) 42 44 42 44
3
Measured in a hard room of approx. 10 m
2
, with 2,5 metres to ceiling and medium absorption.
2
Measured at 1 metre distance in free area.
2
Measured at 1 metre distance in free area.
