Dantherm HCV 3 Installation And Service Guide

73
060783 • Version 1.3 • 26.04.2011
Wiring diagram, continued
Diagram, continued
No. Description No. Value
J8 By-pass DC Power output 1
2
12 V / 0 V
12 V / 0 V
J9 Optional Collector 1
2
3
4
NC
NC
NC
NC
J10 Filter Reset 1
2
+12 V Ext
Reset
J12 RS-485 Interface (Modbus) 1
2
3
4
5
+12 V Ext
0 V Ext
Earth
RS-485 Data +
RS-485 Data -
J14 Humidity Sensor RH3 1
2
3
4
+3,3 V
SCK (Serial Clock)
SDA (Serial Data)
0 V
J16 By-pass Power Jumper (DC) 1
2
3
4
5
6
+12 V for By-pass
NC
+12 V from Main Board
0 V Ext
NC
0 V By-pass
J17 By-pass Power Jumper (AC) 1
2
3
4
5
6
L – 230 VAC for By-pass
NC
L - 230 VAC from Power Supply
N - 230 VAC for By-pass
NC
N – 230 VAC from Power Supply
