List HCV 4
Spare parts list including spare parts numbers:
Item
HCV 4
Description
1
063680
Mounting rail
2
062064
Filter reset button, FRB
3
062060
Print MPCB
4
062019
Fan, diameter 133 mm, 650 mm cable
5
062019
Fan, diameter 133 mm, 650 mm cable
6
070760
Cabling, complete set
7
070784
Temperature sensor, cable set, wall
8
070767
Humidity sensor 1150 mm
9
070765
Counterflow cable with plug, 1600 mm
10
062045
Power cable with plug, 1150 mm, P1150
11
062046
Counterflow cable with plug, 1150 mm, MC1150
12
062023
Rail for drip tray, 475x50 mm
13
062063
Supply cable, 230 V AC
14
062059
HCP4 control panel
15
063367
Front cover, bottom
16
063366
Front cover, top
17
062066
Magnet, 64x10 mm
18
062018
Polystyrene front, complete
19
062694
Filter cover
20
070775
Heat exchanger 336 mm with insulation
21
064405
Hinges x 10
22
062062
Connection panel, CP: IEC plug
23
062065
Pressure tube connection for pressure measurement
