STXC2 User’s guide
Version 2.0
8 of 30
2. User’s guide.
2.1 Main menu.
When there has been no activity for a few minutes the display will show the following primary
menu:
The actual room temperature, supply air volume and the running program step are shown on the
display.
If the ventilation unit is equipped with damper motors (ON/OFF or modulated 0-10V) on the fresh
air duct and exhaust air duct or a humidity sensor, the status for these is also shown on the display.
By pressing Enter the display shifts to the main menu. The backlight on the display is turned on. If
no push button has been activated within 2 minutes, the STCU automatically turns back to the
primary menu and the back light is turned off.
The push buttons and shift between the sub menus.
Main menu Monday 12:21
Adjustm. / clock
Ventilation / climate
Alarms
Technical data
Actual room temp C +20,7
Supply m3h 02500
Monday 12:21
Actual prog no 01
