STXC2 User’s guide
Version 2.0
14 of 30
2.6 Setting a week program.
From the main menu the sub menu Adjustm. / clock is selected. Select the sub menu Program step:
Pick a specific data point with the push buttons and .
In the data point Program step no the program step is selected (maximum 20 steps), which is going
to be changed.
Individual days can be selected such as Monday, Tuesday, Wednesday etc., workdays can be
selected (Monday to Friday), weekends can be selected (Saturday and Sunday) and a full week
(Sunday to Monday).
Time (24 hour clock), temperature and air volume are selected by the push buttons + and –.
After inputting the settings in a program step press Enter to save. The next program step can be
selected in the data point Program step no.
In any unused program steps up to 20, the data point Time has the setting --: --. The control system
will then jump to the next program step.
The data point setting Time has the default factory setting --: --.
Setting for mixing section
If the ventilation unit is equipped with damper motors in a mixing section, fresh air setting can be
chosen from 0 (closed) to 100 (fully open).
Adjustm / clock
Program step
Program step no 01
Ventilation m3h 02500
Day(s) Monday
Time 08:00
Temp set point C 20
Night cooling No
Main menu Monday 12:21
