3.11 Electrical connection
Be careful!
All electrical connection works must meet local electrical equipment installation
standards, done by qualified professionals.
It is forbidden to connect the power supply beyond the specified voltage and frequency;
Before the connecting the power supply, the electrical point should be checked to ensure that
its voltage and frequency fluctuation does not go beyond ±10%;
Unit must be grounded and turn off power during checking work.
3.12 Sensitive elements connection
The installation of temperature and humidity detection devices (controller) should follow the
requirements as below˖
Temperature and humidity detection devices should be installed above ground 1m - 1.5m, to
ensure the device can detect the humidity of the dehumidifying area;
Detection device should be installed away from dry air or wet air or airflow from outside;
Temperature and humidity detectors should stay away from cooling equipment,
do not directly exposed to sunshine place, as the change of the temperature will affect the
actual assessment;
External control system must be compatible with the low voltage control circuit of
dehumidification equipment.
3.13 Wiring Diagram: DanVex DD
Wiring diagrams the dehumidifier pasted on the body, and are available in the appendix of this
manual.
3.14 Wiring Diagram: DanVex DD-F
Wiring diagrams the dehumidifier pasted on the body, and are available in the appendix of this
manual.
