Data Aire dap4 User Manual

120
Alarm Screen
Description &
Classification
Possible Causes
Corrective Actions
• Unusual rate of
building humidity gain
• Loose Connection
• Out of calibration
• Faulty Sensor
• Check Connection
• Calibrate sensor
• Check Humidity sensor and
replace if needed
Low Humidity
The return air
humidity is
lower than the
low humidity
alarm limit
*Warning
• Humidity is to low
• Humidity alarm set
point needs to be
adjusted
• Humidifier not working
properly
• Out of calibration
• Faulty Humidity
sensor
• Check humidity in the room
• Check Low humidity alarm set
point (range 10%-65%)
• Check Humidifier
• Calibrate sensor
• Check Sensor replace if needed
Humidifier
failure
Humidifier
malfunction
*Warning
• Low water pressure
• Overcurrent detected
or no current
• Fill system failure
• End of cylinder life
• Incorrect settings of
digital input on the
controller
• Check water pressure
• Check current, and add minerals
to the water if necessary
• Check water supply and fill
valve
• Replace tank if necessary
• Go to Menu L- Configure I/O and
change the Humidifier Fault
Switch action setting
Discharge Air
Low Temp
Discharge air
temperature is
below alarm
set point
*Warning
• Supply air temperature
is below set point
• Dehumidification set to
low or Fan Speed
Assist setting may be
running fan too slow.
• Adjust the Discharge Air alarm
limit set points (range 45º-60º).
• Increase Dehum setpoint, Lower
Dehum Fan Speed Assist
setting.
• Increase heat load
