21 • Mini dap4 User Manual
3.8 MENU H - CALIBRATE SENSORS
MENU H allows calibration of the unit installed sensors (the Service Level password is required for entry)
Return air temperature and humidity sensors are standard with Data Aire units. Dependent on options and equipment
type, a discharge air and chilled water sensor may be installed in the unit.
Press the UP or DOWN key until “H - Calibrate Sensors” appears and is highlighted. Press the ENTER key.
The following will be displayed on the display module (values are for reference only):
▼ Press the ENTER key to move the cursor. The cursor will ash at the Offset. By pressing the UP (to increase) or
DOWN (to decrease) keys the Offset can be changed.
Once the change has been made, press the ENTER key and the cursor will move to the title block of the screen. The
Offset change is now entered and stored.
To move to the next screen, press the DOWN key.
The following will be displayed (values are for reference only):
▼ Press the ENTER key to move the cursor. The cursor will ash at the Offset. By pressing the UP (to increase)
DOWN (to decrease) keys the Offset can be changed.
Once the change has been made, press the ENTER key and the cursor will move to the upper portion of the screen.
The Offset change is now entered and stored.
To move to the next screen, press the DOWN key.
The following will be displayed (values are for reference only):
Analog Input
Humidity Sensor
Input B02
Offset 0.0
Value 50.0
Analog Input
Return Air Temp Sensor
Input B01
Offset 0.0
o
F
Value 72.0
o
F
Analog Input
Discharge Air Sensor
Input B09
Offset xx.x
Value xx.x
To Next Page
