3.12 MENU L - Congure I/O (factory use only)
Menu L is a factory for conguring the unit’s digital inputs and the unit’s analog inputs and outputs. This requires the
Factory Level password and entry should be limited to Data Aire factory and service personnel.
▼ Press the UP or DOWN key until “L. Congure I/O” appears and is highlighted. Press the ENTER key.
The following will be displayed (values are for reference only):
Move the cursor by pressing the ENTER key. Move the cursor to change the setting.
The following can be changed by pressing the DOWN key:
Channel – Open or Closed
Delay – the range is 0 – 999 seconds
Status – Open or Closed
Once a selection or selections have been made, move the cursor to the title block by pressing the ENTER key
▼ Press the DOWN key to view the next screen.
The following will be displayed (values are for reference only):
Move the cursor by pressing the ENTER key. Move the cursor to change the setting.
The following can be changed by pressing the DOWN key:
Channel – Open or Closed
Delay – the range is 0 – 999 seconds
Status – Open or Closed
Once a selection or selections have been made, move the cursor to the title block by pressing the ENTER key.
▼ Press the DOWN key to view the next screen.
Digital Input
C1 LOW PRESSURE SW
Channel ID2
Action: Open
Delay: 5s
Digital Input
C1 HI PRESSURE SW
Channel ID1
Action: Open
Delay: 5s
Status: Open
