92 Error Recovery and Messages

3. Pressthecartridgereleasebuttonandpulloutthefilmcartridge.Thecartridgemaybe

difficulttopulloutifthecardisstucktothelaminatefilm.Pulloutthecartridgeslowlyto

avoiddroppingthelaminatefilmfromthecartridge.Ifthecartridgecannotberemoved,call

for

service.

4. Removethejogdialfromthecardprinterandattachittothejogdialinsertionslot.

5. Turnthejogdialcounterclockwisetodischargethe

cardfromthecardoutlet.

6. Inspectthecartridge:

 Ifthematerialonthecartridgeisinonepiece:

 Turnthebottom‐sidecartridgetak e‐upknobcounter‐

clockwiseuntilalldamagedmaterialiswoundneatlyon

thetake‐upspool.

 Turnthetop‐sidecartridgetak e‐upknobclockwiseuntil

allthedamagedmaterialiswoundneatlyonthetake‐up

spool.

 Ifthematerialissplitorbroken:

 Trimtheendsofthebrokenportionsevenly.

 Aligntheendofthesupplymaterialwiththetak e‐up

spoolandapplytapetosecureit.

 Turnthematerialontothetak e‐upspooluntilthe

mendedportioniswoundtwoorthreeturns.

7. Replacetheloadedlaminatorcartridgeintheprinteruntilit

clicksintoposition.

8. Closethelaminatordoor.Thelaminatorreinitializesautomatically.

Supply Roll

Take-up Spool

Tape

DataCard LM200 User Manual
