10 Introduction

Laminator Operator Panel

Thestatusofthelaminatoris displayedonthecardprinter ’sLCDpanelandontheStatusMonitor

ofthePCconnectedtothecardprinter.Thelaminatoroperatorpanelhastwostatuslightsand

oneoperatorbutton,shownbelow:

RedStatusLight Ablinkingorsteadyredlightindicatesalaminatorerror.

BlueStatusLight Ablinkingorsteadybluelightindicatesthatthe

laminatorisfunctioningnormally.

OperatorButton Pressthisbuttonafterloadingalaminatorfilmcartridge,

toresetthelaminatorsettings.

Whennofilmcartridgeisloaded,presstheoperator

button

fortwosecondsorlongertostartthecleaning

operation.Referto“CleaningtheCardFeedRollersand

HeatRoller”onpage 76forcleaninginstructions.

DataCard LM200 User Manual
