DataCard SD160 Quick Install Guide

Contents
Step 1: Prepare the Printer ................................................................................. 2
Step 2: Plug In and Power On the Printer ....................................................... 4
Step 3: Set Up the PC .......................................................................................... 5
Step 4: Install the Printer
(USB): Install a USB Printer ............................................................................ 7
(Network): Install a Network Printer .......................................................... 9
Step 5: Print a Sample Card .............................................................................. 12
The printer must be used as installed and recommended by Datacard. You may not modify the printer or
how it is used without written permission. Changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
Installation Steps
*Supplies sold separately
Warning: This product contains chemicals, including lead,
known to the State of California to cause cancer, and birth
defects or other reproductive harm. Wash hands after handling.
For more information on this warning, refer to:
www.datacard.com/califpropwarning.

DataCard SD160 Specifications

General

Print Technology	Dye Sublimation
Print Resolution	300 dpi
Connectivity	USB 2.0
Power Requirements	100-240 VAC, 50/60 Hz
Card Capacity	100 cards input hopper, 25 cards output hopper
Card Size	CR80 (85.6 mm x 54 mm)
Operating System Support	Windows 7, Windows 8, Windows 10
Card Thickness	0.020" to 0.030" (0.51 mm to 0.76 mm)
Print Speed	Up to 150 cards per hour (YMCKT)
