Page 25
Site requirements
Operating environment
• Relative humidity: 20% to 80% non-condensing
• Temperature: 60° F to 95° F (15° C to 35° C)
Electrical requirements
• The power supply is rated at 100-240 VAC, 50-60 Hz,
1.0 amp. (The power supply adjusts to any power within
this range.)
• Single phase, 3-wire, grounded receptacle only.
Physical requirements
• The printer weighs less than 9 pounds (4 kg). The
weight depends on the options installed.
• Printer dimensions are 16.5 inches (419 mm) long, 7.8
inches (198 mm) wide, and 9 inches (229 mm) high.
• The clearance required 1 inch (2.5 cm) at the back, 2
inches (5 cm) on the left side, and 10.5 inches (26.7
cm) above the printer to open the cover.
Do not use the printer in a dirty environment. Do not use
the printer in a closed compartment. Do not block air flow
around the printer.
