4 Preparing for Installation
Providing Adequate Printer Ventilation
Ventilation holes are provided for the cooling fans on the bottom and sides of the unit. Install the
unit so the sides are at least 7.9 inches (200mm) away from the surrounding wall. Keep the
back of the unit at least 3.9 inches (100mm) away from a wall. Do not place any objects on top
of the unit.
Installing the Card Hopper
With the open area of the card hopper cover toward the printer, slide the card hopper cover into
the grooves of the card hopper.
The card hopper can hold up to 100 0.030 inch (0.76mm) thick cards or 280
0.010 inch (0.25mm) thick cards.
