DM4380 – Installation Guide
Technical Specification
204.4336.00 - October/2019
35
7 TECHNICAL SPECIFICATION
7.1 INTERFACES
Interfaces
DM4380 12XS+3CX
Console (RJ45)
1
Management Ethernet (RJ45)
1
USB Host (type A)
1
USB Device (type B)
1
1000Base-X/10GBase-X (SFP+)
12
40GBase-X/100GBase-X (QSFP28)
3
Table 20 – DM4380 Interfaces
7.2 POWER SUPPLY AND CONSUMPTION
7.2.1 Power Supply PSU 125 AC/DC
PSU 125 AC
PSU 125 DC
Connector type
IEC 320/C14
Terminal Block
Nominal Operating voltage
100 to 240Vac (± 10%)
50/60Hz
-48 to -60Vdc (± 20%)
Nominal Input Current
1.5 A @ 100Vac*
0.63 A @ 240Vac*
3.3 A @ -48Vdc*
2.6 A @ -60Vdc*
Maximum Input Current
1.66 A
3.30 A
Output Voltage
12V (± 5%)
12V (± 5%)
Output Current
10.5 A (± 5%)*
10.5 A (± 5%)*
Power Efficiency
>80%
>80%
Table 21 – AC/DC Power Supplies specifications
* Maximum values for the Power Supplies
7.2.2 DM4380 System
DM4380 12XS+3CX
Typical Consumption
(Watts)
PSU 125 DC
108W
PSU 125 AC
108W
Maximum Consumption
(Watts)
PSU 125 DC
150W
PSU 125 AC
150W
Maximum Current
(Amperes)
PSU 125 DC
3.3A
PSU 125 AC
1.66A
Table 22 – DM4380 Power Consumption
7.3 PHYSICAL SPECIFICATIONS
DM4380 12XS+3CX
Height
44 mm
Width (with brackets)
482 mm
Width (without L brackets)
444 mm
Depth
265 mm
Weight
3.00 kg
Table 23 – DM4380 Physical Specifications
