10.7.1. Equipment Status Menu
# --------------------------------------------------------------------------
# D A T A C O M [ 1 ]
# DM991C - G.SHDSL Modem - E1 and V.35 Interfaces
# --------------------------------------------------------------------------
# Equipment Status
#
# Current test :[ No active tests ]
# Device 2048 clock source :[ Internal (regen. failed) ]
# Up time :[ 0 days 1h:54m:51s ]
# Number of after factory resets :[ 16 ]
#
#
#
#
#
#
#
#
#
#
#
# --------------------------------------------------------------------------
# <P>revious <ESC> Exit <ENTER> Refresh <N>ext
# --------------------------------------------------------------------------
• Current test: indicates if any interface is in test.
• Device 2048 clock source - general synch source: indicates the configured transmission
clock status.
• Up time: time the equipment has been running since the last reset.
• Number of after factory resets: number of equipment resets since the equipment left the
factory.
10.7.2. G.shdsl Interface Status Menu
# --------------------------------------------------------------------------
# D A T A C O M [ 1 ]
# DM991C - G.SHDSL Modem - E1 and V.35 Interfaces
# --------------------------------------------------------------------------
# G.SHDSL Status
#
# Operation :[ Active ]
# Current test :[ Not running ]
# BERT test result :[ Not running ]
# Link :[ No carrier ]
# Loop attenuation :[ Not trained ]
# SNR margin :[ Not trained ]
# Data rate :[ Not trained ]
# Frame mode :[ Not trained ]
#
#
#
#
#
#
#
# --------------------------------------------------------------------------
# <P>revious <ESC> Exit <ENTER> Refresh <N>ext
# --------------------------------------------------------------------------
• Operation: indicates if the interface is active.
• Current test: indicates if there is any test active on the interface.
• BERT test result: indicates BERT test results.
• Link: shows the G.shdsl link status. The following status are possible:
o Synch OK;
o No carrier;
