• CT108 (DTR): indicates if the CT108 signal is active or not. If configured to be ignored
“Forced ON” will show.
• CT109 (DCD): if active indicates that the aggregate is operating properly and the data
received is valid (CT104).
• CT113 (XTC): in case the CT113 is enabled, indicates it is operating on the configured
frequency. “Ignored” means disabled, “On” means operating properly and “Off” means not
operating properly.
• CT128 (ERC): in case the CT128 is enabled, indicates it is operating on the configured
frequency. “Ignored” means disabled,” On” means operating properly and “Off” means not
operating properly.
• CT103 (TD): Report the type of information transmitted for digital interface.
• CT104 (RD): Report the type of information received for digital interface
10.7.4. E1 Interface Status Menu
# --------------------------------------------------------------------------
# D A T A C O M [ 1 ]
# DM991C - G.SHDSL Modem - E1 and V.35 Interfaces
# --------------------------------------------------------------------------
# E1 Status
#
# Operation :[ Active ]
# Current test :[ Not running ]
# Link :[ No carrier ]
#
#
#
#
#
#
#
#
#
#
#
#
# --------------------------------------------------------------------------
# <P>revious <ESC> Exit <ENTER> Refresh <N>ext
# --------------------------------------------------------------------------
• Operation: indicates if the interface is active.
• Current test: indicates if there is any test active in the interface.
• Link: shows the E1 link status indicating if there is carrier present, frame, CAS, CRC4
synch, remote alarm or if it is totally in synch.
