Datacom DM991CE - Bridge Interface Status Menu; Performance Menu

Product Manual - DM991 Series V Family - 204.4092.08 59
10.7.5. Bridge Interface Status Menu
# --------------------------------------------------------------------------
# D A T A C O M [ 1 ]
# DM991CE - G.SHDSL Modem With Ethernet Bridge
# --------------------------------------------------------------------------
# Bridge Status
#
# Operation :[ Active ]
# Link :[ No Link ]
# Auto Negotiation :[ Unavailable ]
#
#
#
#
#
#
#
#
#
#
#
#
# --------------------------------------------------------------------------
# <P>revious <ESC> Exit <ENTER> Refresh <N>ext
# --------------------------------------------------------------------------
• Operation: indicates if the interface is active.
• Link: indicates if there is synch on the interface.
• Auto negotiation: indicates if the equipment connected using full-duplex mode or half-
duplex mode.
10.8. Performance Menu
On this menu the following G.shdsl interface performance information are available.
Pressing ENTER, the information will be updated. The key "R" restarts the performance counters.
# --------------------------------------------------------------------------
# D A T A C O M [ 1 ]
# DM991C - G.SHDSL Modem - E1 and V.35 Interfaces
# --------------------------------------------------------------------------
# G.SHDSL Performance
#
# Code violations (CV) :[ 0 ]
# Errored seconds (ES) :[ 0 ]
# Severely errored seconds (SES) :[ 0 ]
# LOSW seconds (LOSWS) :[ 0 ]
# Unavailable seconds (UAS) :[ 0 ]
# Loop attenuation (dB) :[ Not trained ]
# Signal quality (dB) :[ Not trained ]
# Time since last counters reset (s):[ 7741 ]
#
#
#
#
#
#
#
# --------------------------------------------------------------------------
# <ESC> Back <ENTER> Refresh <R>eset Counters
# --------------------------------------------------------------------------
• Code Violation (CV): CRC errors counter on the G.shdsl interface occurred during a
accumulated period.
• Errored Seconds (ES): counter of 1 second intervals during which one or more anomalies
on the CRC and/or one or more LOSW defects are verified.
• Severely Errored Seconds (SES): counter of 1 second intervals during which at least 50
anomalies on the CRC or one or more LOSW defects happen.
