Product Manual - DM991 Series V Family - 204.4092.08 57
o Handshake;
o Non-aligned TDM (only for model 4W operating with 4 wire
o Training;
o LOSW Defect;
o LOSW Flaw;
o No CRC synch;
o No CAS synch.
• Loop attenuation: shows the status of the Loop Attenuation Defect.
• SNR margin: shows the status of the Signal-Noise Relation Defect.
• Data rate: indicates the interface transmission rate (number of channels) negotiated
during the handshake.
• Frame mode: Shows the interface operation mode (synchronous or plesiochronous)
negotiated during the handshake.
• Annex: Shows the Annex (A or B) negotiated during the handshake.
• Modulation: Shows the modulation (16-TCPAM) negotiated during the handshake.
10.7.3. Digital Interface Status Menu
# --------------------------------------------------------------------------
# D A T A C O M [ 1 ]
# DM991C - G.SHDSL Modem - E1 and V.35 Interfaces
# --------------------------------------------------------------------------
# V.35 Status
#
# Operation :[ Active ]
# Current test :[ Not running ]
# CT105 (RTS) :[ Forced ON ]
# CT108 (DTR) :[ Forced ON ]
# CT109 (DCD) :[ ON ]
# CT113 (XTC) :[ Ignored ]
# CT128 (ERC) :[ Forced OFF ]
# CT103 (TD) :[ All 1s ]
# CT104 (RD) :[ All 1s ]
#
#
#
#
#
#
#
#
# ---------------------------------------------------------------------------
# <P>revious <ESC> Exit <ENTER> Refresh <N>ext
# ---------------------------------------------------------------------------
• Operation: indicates if the interface is active.
• Current test: indicates if there is any test active on the interface.
• CT105 (RTS): indicates if the CT105 signal is active or not. If configured to be ignored
“Forced ON” will show.
Available in FW version 110.
Available in FW version 110.
